60 Series Quick Connect Couplings

60 Series - 3/8" Flow Size Quick Connect Couplings

Nordson MEDICAL Offers Cost-Efficient, High-Performance Line of LinkTech Quick Connects

When fluid management applications ranging from high level disinfection to biopharm fluid transfer to therapeutic hypothermia require durable, serviceable connections with increased fluid volumes – Nordson MEDICAL’s line of LinkTech 60-Series quick connects delivers cost-efficient, high-performance solutions.

These 3/8-inch couplings provide increased flow capacity and are available in valved or non-valved configurations. The LinkTech 60-Series Quick Connects provide serviceable connections with large, robust thumb latches that provide an audible click when coupled, internal shut-off valves or straight-thru designs, and barbed or threaded terminations.

Whether you choose food or medical-grade materials with black-out options for greater UV resistance, the 60-Series can be interconnected with each other or with similar industry thumb-latch, high-flow couplings – making them an ideal option for cost-efficient high-performance quick connects.

Shop Now

3/8" Flow Size

  • Advanced plastic thumb-latch couplings
  • Valved and nonvalved configurations
  • Large, robust thumb latch for easy use
  • Great chemical resistance
  • Strong, panel-mount designs
  • "Black-out" color options for UV resistance
  • Interconnect with each other and with similar industry thumb-latch high-flow couplings
Visit Online Store

60 Series Quick Connect Couplings Technical Information

Materials
  • Bodies & Terminations
    • 60PP Series (Grey): Medical-grade polypropylene
    • 60PP Series (Black): UV-resistant medical-grade polypropylene
    • 60PS Series (White): Food-grade Udel® polysulfone (PSU)
    • 60PS Series (Black): UV-resistant food-grade Udel polysulfone
  • Internal Valves
    • 60PP Series (Grey): Medical-grade polypropylene
    • 60PP Series (Black): UV-resistant medical-grade polypropylene
    • 60PS Series (White): Food-grade Udel polysulfone
    • 60PS Series (Black): UV-resistant food-grade Udel polysulfone
  • Internal Valve Springs
    • 316 Stainless Steel
  • Latch Spring
    • 300 Grade Stainless Steel
  • O-Rings
    • Peroxide-cured ethylene propylene diene monomer (EPDM)
    • Other options available
  • Thumb Latch
    • 60PP Series (Grey): Medical-grade polypropylene
    • 60PP Series (Black): UV-resistant medical-grade polypropylene
    • 60PS Series (White): Food-grade Udel polysulfone
    • 60PS Series (Black): UV-resistant food-grade Udel polysulfone
Sterilization
  • Not available
Fits Tubing IDs
  • 1/4" (6.4 mm)
  • 3/8" (9.5 mm)
  • 1/2" (12.7 mm)
  • 3/4" (19.0 mm)
Flow Capacity
  • 3/8" (9.5 mm)
Operating Pressure
  • 60PP Series (Grey and Black): Vacuum to 60 psi (4.2 bar)
  • 60PS Series (White and Black): Vacuum to 125 psi (8.6 bar)
Temperature
  • 60PP Series (Grey and Black): 32° F (0° C) to 160° F (71° C)
  • 60PS Series (White and Black): -40° F (-40° C) to 280° F (138° C)

Markets
